MAGSWITCH 90 Degree Angle Workholding Fabrication Magnets
MAGSWITCH 90 Degree Angle Workholding Fabrication Magnets
Description
Magswitch 90 Degree welding angles are the most versatile in the market. Featuring the benefits of Magswitch, including incredible power and precision control, Magswitch 90 Degree Angles are easy to use, and can be used on larger and heavier steel.
All Magswitch 90 Degree Angles allow you to reposition the magnets up or down on each axis, or reverse from outside to inside. If you want more strength, just add more MagSquares.
Features
- Fixed 90° welding angle
- Incredible power and precision control
- Adjustable - Slide up or down on each axis
- Reversible - inside or outside
- Size for any job - big or small
- Holds flat or round steel
- Use additional MagSquares for increased strength
- Easy turn on/off with 180° turn of the knob.
- Features patented Magswitch® technology for complete on/off control that requires no cleaning.
| Model | 165 | 400 |
| Magnet Strength | 68kg | 181kg |
| Full Saturation Thickness | 6mm | 3.43mm |
| 2:1 Shear Working Load | 8.4kg | 9kg |
| Height | 205mm | 262.9mm |
| Width | 47mm | 133.2mm |
| Length | 205mm | 262.9mm |
| Weight | 0.8kg | 2.8kg |
| Magnetic Pole Footprint | 48 x 31mm | 64 x 41.26mm |
90-Degree Angle 165
90-Degree Angle 400
